Properties of Common Hardwoods & Softwoods used in Truck Trailer Applications

Send us an Inquiry

Modulus of Rupture (MOR) Strength Ratings for Various Species of Wood (psi)

The modulus of rupture reflects the maximum loadcarrying capacity of the species in bending strength and is proportional to the maximum strength or breaking point as borne by the specimen. (1)

  • Purpleheart 21,300 psi
  • Apitong, Keruing 19,900 psi
  • Brazilian Apitong, Angelim Pedra 18,255 psi
  • White Oak 15,200 psi
  • Bamboo 15,050 psi
  • Red Oak 14,300 psi
  • Southern Yellow Pine 13,500 psi

Modulus of Elasticity (MOE) Stiffness Ratings for Various Species of Wood (1000 psi)

The modulus of elasticity ratings as shown below are based on the stiffness or resistance to bending of the particular wood species. These ratings are for the common longitudinal modulus of elasticity not the radial or tangential ratings.(1)

  • Purpleheart 2,420 1000 psi
  • Apitong, Keruing 2,070 1000 psi
  • Brazilian Apitong, Angelim Pedra 2,050 1000 psi
  • Red Oak 1,850 1000 psi
  • Southern Yellow Pine 1,786 1000 psi
  • White Oak 1,780 1000 psi
  • Bamboo 1,576 1000 psi

Janka Hardness Ratings for Various Species of Wood (pounds)

Hardness is defined as resistance to indentation using a modified Janka hardness test, measured by the load required to embed a 11.28-mm (0.444-in.) ball to one-half its diameter. Values presented are the average of radial and tangential penetrations.(1)

  • Purpleheart 1,860 lbs
  • Brazilian Apitong, Angelim Pedra 1,720 lbs
  • Apitong, Keruing 1,520 lbs
  • White Oak 1,360 lbs
  • Bamboo 1,300 lbs
  • Red Oak 1,290 lbs
  • Southern Yellow Pine 750 lbs

Density Ratings for Various Species of Wood (KG per Cubic Meter)

The weight of a wood product is determined by the density of the basic wood structure and by the moisture content of the material. The density of the wood, exclusive of water, varies greatly both within and between species. Variations in density of approximately 10% within a particular species should be considered normal. Moisture makes up part of the weight of wood and should always be taken into consideration. The values below represent the density at approximately 12% moisture content.(1)

  • Purpleheart 1,057 KG/m3
  • White Oak 900 KG/m3
  • Apitong, Keruing 790 KG/m3
  • Red Oak 780 KG/m3
  • Bamboo 750 KG/m3
  • Brazilian Apitong, Angelim Pedra 690 KG/m3
  • Southern Yellow Pine 650 KG/m3

(1) The Wood Handbook - Wood as an engineering material, USDA, General Technical Report 113.
